DIN 444 - Eyebolts - Type B and C

Leading UK Manufacturer of DIN 444 Type B and C Eyebolts.

We specialise in the precision manufacture and supply of high-integrity DIN 444 Type B and C eyebolts, engineered to provide reliable pivoting and hinging anchor points for demanding industrial clamping, locking, and assembly mechanisms.

Utilising advanced forging, threading, and machining processes, we ensure precise thread profiles and accurate shank tolerances, delivering dependable structural performance in accordance with international standards. Whether for standard equipment integration or bespoke dimensions tailored to specific engineering drawings, we provide a complete, high-quality manufacturing solution.

---

A	B		C	D		E	F
mm	MIN mm	MAX mm	mm	MIN mm	MAX mm	mm	MIN mm	MAX mm
M6	35	90	18	13.57	14	6	6.85	7
M8	40	125	22	17.57	18	8	8.85	9
	126	140	28	17.57	18	8	8.85	9
M10	45	125	26	19.48	20	10	11.82	12
	126	150	32	19.48	20	10	11.82	12
M12	55	125	30	24.48	25	12	13.82	14
	126	200	36	24.48	25	12	13.82	14
	201	260	49	24.48	25	12	13.82	14
M16	70	125	38	31.38	32	16	16.82	17
	126	200	44	31.38	32	16	16.82	17
	201	260	57	31.38	32	16	16.82	17
M20	100	125	46	39.38	40	18	21.79	22
	126	200	52	39.38	40	18	21.79	22
	201	260	65	39.38	40	18	21.79	22
M24	100	125	54	44.38	45	22	24.79	25
	126	200	60	44.38	45	22	24.79	25
	201	260	73	44.38	45	22	24.79	25
M30	150	200	72	54.26	55	28	29.79	30
	201	300	85	54.26	55	28	29.79	30
M36	160	200	84	64.26	65	32	37.75	38
	201	300	97	64.26	65	32	37.75	38
M39	160	200	90	69.26	70	35	40.75	41
	201	300	103	69.26	70	35	40.75	41
