DIN 444 - Eyebolts - Type A

Leading UK Manufacturer of DIN 444 Eyebolts.

We specialise in the precision manufacture and supply of high-integrity DIN 444 eyebolts, engineered to provide reliable pivoting and hinging anchor points for general industrial machinery, clamping devices, and locking mechanisms.

Utilising advanced forging, threading, and machining processes, we ensure precise metric threading and a smooth shank profile, delivering dependable structural performance in accordance with international standards. Whether for standard equipment assembly or bespoke industrial requirements, we provide a complete, high-quality manufacturing solution.

---

A	B		C	D		E	F
mm	MIN mm	MAX mm	mm	MIN mm	MAX mm	mm	MIN mm	MAX mm
M6	35	90	18	12.9	14	6	8.52	9
M8	40	125	22	16.9	18	8	10.30	11
	126	140	28	16.9	18	8	10.30	11
M10	45	125	26	18.7	20	10	13.30	14
	126	150	32	18.7	20	10	13.30	14
M12	55	125	30	23.7	25	12	16.30	17
	126	200	36	23.7	25	12	16.30	17
	201	260	49	23.7	25	12	16.30	17
M16	70	125	38	30.4	32	16	18.16	19
	126	200	44	30.4	32	16	18.16	19
	201	260	57	30.4	32	16	18.16	19
M20	100	125	46	38.4	40	18	23.16	24
	126	200	52	38.4	40	18	23.16	24
	201	260	65	38.4	40	18	23.16	24
M24	100	125	54	43.4	45	22	27.16	28
	126	200	60	43.4	45	22	27.16	28
	201	260	73	43.4	45	22	27.16	28
M30	150	200	72	53.1	55	28	33.00	34
	201	300	85	53.1	55	28	33.00	34
M36	160	200	84	63.1	65	32	40.00	41
	201	300	97	63.1	65	32	40.00	41
M39	160	200	90	68.1	70	35	45.00	46
	201	300	103	68.1	70	35	45.00	46
