Long Shank Collared Eyebolts - Metric

Leading UK Manufacturer of Metric Long Shank Collared Eyebolts.

We specialise in the precision manufacture and supply of high-integrity metric long shank collared eyebolts, engineered to provide secure lifting, rigging, and structural anchoring through thick walls, heavy machine housings, and specialized mounting brackets.

Utilising advanced closed-die drop forging and specialised upset forging processes, we compress and align the material's grain flow along the contours of the component, delivering elite tensile strength, ductility, and fatigue resistance. Whether manufactured to standard configurations or customised to precise length requirements, we provide a complete, certified manufacturing solution.

---

A	B	E	F	G	H	SWL Vertical Only	Weight Each
mm	mm	mm	mm	mm	mm	Tonnes	kgs
M10	22	15	9	20	178	0.25	0.2
M12	28	19	11	25	178	0.40	0.2
M14	36	24	14	32	178	0.50	0.5
M16	36	24	14	32	178	0.80	0.5
M18	43	29	17	38	178	1.00	0.8
M20	43	29	17	38	178	1.60	0.8
M22	50	33	20	44	178	1.60	1.0
M24	57	38	22	51	178	2.50	1.5
M30	71	48	28	63	178	4.00	2.9
