Collared Eyebolts with Links - Metric Thread

Leading UK Manufacturer of Metric Collared Eyebolts with Links.

We specialise in the precision manufacture and supply of high-integrity metric collared eyebolts fitted with integral forged links, engineered for complex multi-leg rigging, crane operations, and heavy lifting applications.

Utilising advanced closed-die drop forging and upset forging processes, we compress and align the material's grain flow along the contours of the component, delivering elite tensile strength, ductility, and fatigue resistance compared to machined or cast alternatives. Whether for standard industrial lifting assemblies or bespoke engineering projects, we provide a complete, certified manufacturing solution.

---

Thread Size	B	F	G	H	LINK			SWL	Weight Each
					D	Bd	Ld
mm	mm	mm	mm	mm	mm	mm	mm	tonnes	kgs
M8	39	12	20	27	13	24	53	0.10	0.40
M10	39	12	20	27	13	24	53	0.15	0.40
M12	39	12	20	27	13	24	53	0.20	0.40
M16	39	12	20	27	13	24	53	0.40	0.40
M20	39	12	20	27	13	24	53	1.00	0.50
M24	47	14	23	32	15	29	63	1.60	0.80
M30	60	18	30	41	19	37	80	2.50	1.50
M36	75	23	38	52	24	46	102	4.00	3.00
M42	94	29	47	65	30	58	126	4.50	5.50
M48	94	29	47	65	30	58	126	6.30	5.50
