Leading UK Manufacturer of Shackle Eyebolts (Curved Sides).
We specialise in the precision manufacture and supply of high-integrity shackle eyebolts featuring curved-side geometry.
Engineered for versatile rigging, pivoting, and secure connection applications, these components are designed to provide enhanced clearance and optimal load-bearing alignment in demanding industrial and lifting environments.
Utilising advanced in-house hot-forging and precision-machining processes, we ensure consistent dimensional accuracy and structural integrity. Whether for custom machine design, heavy-duty rigging, or unique hardware requirements, we provide a complete, high-quality manufacturing solution.
| A | B | C | D | E | F | |||
|---|---|---|---|---|---|---|---|---|
| mm | inches | mm | MIN mm | MIN mm | MAX mm | MIN mm | MAX mm | mm |
| M6 | 1/4 | 16 | 6 | 30 | 3000 | 15 | 1500 | Hole drilled to suit customer requirements. |
| M8 | 5/16 | 19 | 8 | 30 | 3000 | 15 | 1500 | |
| M10 | 3/8 | 19 | 10 | 35 | 3000 | 15 | 1500 | |
| 3/8 | 22 | 10 | 35 | 3000 | 15 | 1500 | ||
| M12 | 1/2 | 32 | 13 | 40 | 3000 | 18 | 1500 | |
| M16 | 5/8 | 38 | 16 | 45 | 5500 | 20 | 2000 | |
| M20 | 3/4 | 38 | 20 | 50 | 5500 | 25 | 2000 | |
| M22 | 7/8 | 50 | 22 | 60 | 5500 | 25 | 2000 | |
| M24 | 1 | 50 | 26 | 65 | 5500 | 30 | 2000 | |
| M27 | 1. 1/8 | 60 | 28 | 68 | 5500 | 30 | 2000 | |
| M30 | 1. 1/4 | 60 | 32 | 70 | 5500 | 35 | 2000 | |
| M36 | 1. 1/2 | 60 | 38 | 100 | 5500 | 45 | 2000 | |
| M42 | 1. 5/8 | 90 | 42 | 115 | 5500 | 48 | 2000 | |
| M45 | 1. 3/4 | 102 | 45 | 120 | 5500 | 50 | 2000 | |
| M48 | 2 | 115 | 51 | 135 | 5500 | 60 | 2000 | |
