Leading UK Manufacturer of Palm Eyebolts (Straight Sides).
We specialise in the precision manufacture and supply of high-integrity palm eyebolts featuring straight-sided geometry.
Engineered for specialised mounting, pivoting, and secure attachment applications, these components provide reliable structural performance in industrial hardware, machine linkages, and architectural assemblies.
Utilising advanced in-house hot-forging and precision-machining processes, we ensure consistent dimensional accuracy and structural integrity. Whether for custom machine design or unique hardware requirements, we provide a complete, high-quality manufacturing solution.
| A | B | C | D | E | F | |||
|---|---|---|---|---|---|---|---|---|
| mm | inches | mm | mm | MIN mm | MAX mm | MIN mm | MAX mm | mm |
| M8 | 5/16 | 16 | 8 | 30 | 3000 | 15 | 1500 | Hole drilled to suit customer requirements. |
| M10 | 3/8 | 25 | 10 | 35 | 3000 | 15 | 1500 | |
| M12 | 1/2 | 25 | 13 | 38 | 3000 | 18 | 1500 | |
| --- | 32 | 12 | 45 | 3000 | 18 | 1500 | ||
| M16 | 5/8 | 32 | 16 | 45 | 5500 | 20 | 2000 | |
| 5/8 | 38 | 16 | 45 | 5500 | 20 | 2000 | ||
| M20 | 3/4 | 42 | 20 | 55 | 5500 | 25 | 2000 | |
| 3/4 | 50 | 20 | 60 | 5500 | 25 | 2000 | ||
| M24 | 1 | 51 | 26 | 65 | 5500 | 30 | 2000 | |
| --- | 51 | 24 | 65 | 5500 | 30 | 2000 | ||
| M30 | 1. 1/8 | 60 | 30 | 70 | 5500 | 35 | 2000 | |
| M33 | 1. 1/4 | 65 | 33 | 90 | 5500 | 40 | 2000 | |
| M39 | 1. 1/2 | 90 | 39 | 95 | 5500 | 45 | 2000 | |
| M56 | 2. 1/4 | 115 | 56 | 120 | 1000 | 50 | 800 | |
| M64 | 2. 1/2 | 130 | 64 | 140 | 1000 | 60 | 800 | |
| M72 | 2. 3/4 | 150 | 72 | 165 | 1000 | 75 | 800 | |
| M76 | 3 | 150 | 76 | 170 | 1000 | 85 | 800 | |
