SN 425 - Hammerhead T Bolts

Leading UK Manufacturer of SN 425 Hammerhead T Bolts.

We specialise in the precision manufacture and supply of high-integrity SN 425 hammerhead T bolts, engineered to meet exact technical specifications similar to DIN 261 for heavy industrial and structural applications.

Offering hot-forged sizes ranging from M24 up to M100 and lengths of up to 6000mm, we deliver robust fastening solutions tailored to the most demanding operating environments.

Utilising advanced in-house hot-forging, precision machining, and thread rolling processes, we ensure consistent dimensional accuracy and structural performance across every batch. Whether for standard construction requirements or bespoke material grades and head forms, we provide a complete, high-quality manufacturing solution.

---

D	D1	B	H	DB	K	N	M	R	T max	L
mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm
M24	20	100	12	-	15	24	43	2	-	To suit customer requirements.
M30	26	120	15	-	19	30	54	2	-
M36	31	160	18	M12	23	36	66	3	23
M42	37	180	21	M12	26	42	80	3	23
M48	42	210	24	M12	30	48	88	3	23
M56	49	250	28	M16	35	56	102	4	30
M64	57	280	32	M16	40	64	115	4	30
M72	65	300	36	M16	45	72	128	4	30
M80	73	320	36	M20	50	80	140	5	33
M90	83	360	45	M20	55	90	155	5	33
M100	93	400	45	M20	62	100	170	5	33
