Leading UK Manufacturer of DIN 529 Type G Anchor Bolts.
We specialise in the precision manufacture and supply of high-integrity DIN 529 Type G anchor bolts.
Engineered with a forged countersunk style head geometry, this design provides a robust mechanical anchor point, locking securely into concrete and masonry foundations to resist high pull-out forces.
Utilising advanced in-house hot-forging and machining processes, we ensure consistent dimensional accuracy and structural performance in accordance with the DIN 529 standard. Whether for standard construction requirements or bespoke modifications, we provide a complete, high-quality manufacturing solution.
| D | A | C | B | L |
|---|---|---|---|---|
| mm | mm | mm | mm | mm |
| M8 | 20 | 5 | To Customer Requirements | |
| M10 | 25 | 6 | ||
| M12 | 30 | 7 | ||
| M16 | 40 | 10 | ||
| M20 | 50 | 12 | ||
| M24 | 60 | 14 | ||
| M30 | 75 | 18 | ||
| M36 | 90 | 22 | ||
| M42 | 105 | 25 | ||
| M48 | 120 | 29 | ||
| M56 | 140 | 34 | ||
| M64 | 160 | 38 | ||
| M72 | 180 | 43 | ||
