Swivel Eyebolts - Increased Eye Thickness

Leading UK Manufacturer of Swivel Eyebolts with Increased Eye Thickness.

We specialise in the precision manufacture and supply of high-integrity swivel eyebolts featuring increased eye thickness.

Engineered for critical rotating and suspension applications, these components provide enhanced structural durability and load-bearing stability, particularly where high-wear conditions or heavy-duty requirements are present.

Utilising advanced in-house hot-forging and precision-machining processes, we ensure consistent dimensional accuracy and structural integrity.
Whether for custom machinery, offshore rigging, or unique hardware requirements, we provide a complete, high-quality manufacturing solution.

---

A		B	C	D		E		F
mm	inches	mm	MIN mm	MIN mm	MAX mm	MIN mm	MAX mm	mm
M6	1/4	19	8	30	160	15	140	Hole drilled to suit customer requirements.
		25	10	35	160	15	140
		25	13	35	160	15	140
M8	5/16	25	10	35	160	15	140
		25	13	35	160	15	140
		38	16	40	165	15	135
		42	20	45	170	15	140
		51	25	50	160	15	140
M10	3/8	25	13	35	160	15	140
		32	13	40	165	15	140
		38	16	45	165	15	140
		42	20	45	170	15	140
		51	22	50	175	15	140
		51	25	50	175	15	140
		60	30	55	180	15	140
M12	1/2	25	14	40	210	20	190
		38	16	50	220	20	190
		42	20	55	220	20	190
		51	22	55	225	20	190
		51	25	55	225	20	190
		62	24	60	230	20	190
		60	30	60	230	20	190
M16	5/8	35	17	45	1500	20	1400
		38	19	50	270	20	240
		42	20	50	270	20	240
		51	25	55	275	20	240
		62	24	60	280	20	240
		60	30	60	280	20	240
		60	32	60	280	20	240
M20	3/4	45	25	52	1500	25	1400
		51	25	55	275	25	240
		62	24	60	280	25	240
		60	30	60	280	25	240
		60	32	60	280	25	240
M24	---	51	28.5	60	1500	25	1400
	1	60	30	65	280	25	240
		60	32	70	280	25	240
M30	1. 1/8	60	32	70	280	30	240
		60	38	70	280	30	240
M33	1. 1/4	65	38	75	280	35	240
M36	1. 3/8	65	38	80	1500	40	1400
