Eye Nuts - Standard

Leading UK Manufacturer of Standard Eye Nuts.

We specialise in the precision manufacture and supply of high-integrity standard eye nuts, engineered to provide reliable lifting, suspension, and anchoring points for industrial machinery, electrical equipment, and structural assemblies.

Utilising advanced hot-forging and precision-machining processes, we ensure consistent thread accuracy and structural load-bearing capacity. Whether for standard commercial requirements or bespoke designs tailored to unique engineering drawings, we provide a complete, high-quality manufacturing solution.

---

A		B	C	D	E	F	G	SWL METRIC	SWL IMPERIAL
METRIC	IMPERIAL	mm	mm	mm	mm	mm	mm	kgs	cwt
M8	---	44	13	19	22	78	22	200	---
M10	3/8	44	13	19	22	78	22	300	5
M12	1/2	44	13	19	22	78	22	500	10
M14	---	44	13	19	22	78	22	500	---
M16	5/8	44	13	19	22	78	22	800	16
M18	---	48	16	29	26	86	26	1000	---
M20	3/4	48	16	29	26	86	26	1200	24
M22	7/8	48	16	29	26	86	26	1600	32
M24	1	54	19	35	38	105	38	2200	44
