Leading UK Manufacturer of DIN 529 Type A Anchor Bolts.
We specialise in the precision manufacture and supply of high-integrity DIN 529 Type A anchor bolts.
Designed as a versatile stone bolt with curled end, this type is engineered for secure anchoring in masonry and concrete applications where robust structural retention is required.
Utilising advanced in-house hot-forging, bending, and precision-machining processes, we ensure consistent dimensional accuracy and structural performance in accordance with the DIN 529 standard. Whether for standard construction requirements or bespoke modifications, we provide a complete, high-quality manufacturing solution.
| D | A | C | B | L |
|---|---|---|---|---|
| mm | mm | mm | mm | mm |
| M8 | 24 | 45 | To Customer Requirements | |
| M10 | 30 | 55 | ||
| M12 | 36 | 65 | ||
| M16 | 48 | 85 | ||
| M20 | 60 | 105 | ||
| M24 | 75 | 125 | ||
| M30 | 95 | 155 | ||
| M36 | 115 | 190 | ||
| M42 | 135 | 220 | ||
| M48 | 155 | 250 | ||
| M56 | 180 | 290 | ||
| M64 | 200 | 335 | ||
| M72 | 240 | 370 | ||
