Lift Suspension Eyebolts - Round

Leading UK Manufacturer of Round Eye Lift Suspension Eyebolts.

We specialise in the precision manufacture and supply of high-integrity round lift suspension eyebolts, produced in accordance with BS 5655: Part 8.

Engineered for critical lifting, suspension, and support applications, these components provide reliable structural integrity in demanding industrial and lift-industry environments.

Utilising advanced in-house hot-forging and precision-machining processes, we ensure consistent dimensional accuracy and structural load-bearing capacity. Whether for standard infrastructure requirements or bespoke designs tailored to unique engineering drawings, we provide a complete, high-quality manufacturing solution.

---

A	WIRE ROPE DIA	SWL Vertical Only	PROOF FORCE	MINIMUM BREAKING FORCE	B	C	F	G	WEIGHT EACH
mm	mm	Tonnes	kn	kn	mm	mm	mm	mm	kgs
M10	6 - 6.5	0.20	4.12	20.60	10	15	150	115	0.13
							300	230	0.22
M12	8	0.31	6.23	31.15	12	15	150	115	0.18
							300	230	0.31
M16	10	0.49	9.73	48.65	15	21	300	230	0.64
							450	345	0.88
							600	460	1.11
M16	11	0.60	11.78	58.90	17	21	300	230	0.64
							450	345	0.88
							600	460	1.11
M20	13	0.83	16.45	82.25	20	24	450	345	1.45
							600	460	1.82
							750	575	2.15
M24	16	1.27	25.00	125.00	24	27	450	345	2.09
							600	460	2.65
							750	575	3.18
M30	19	1.79	35.17	175.85	29	34	450	345	3.49
							600	460	4.32
							750	575	5.15
M30	22	2.40	47.17	235.85	33	37	450	345	3.55
							600	460	4.38
							750	575	5.21
