Leading UK Manufacturer of Anchor Sockets with Plate
We specialise in the precision manufacture and supply of high-integrity anchor sockets with plates, engineered to provide robust, heavy-duty foundation fixing and secure internal thread anchorage points for structural concrete, civil engineering, and large-scale industrial projects.
Utilising advanced in-house plate profiling, welding, threading, and fabrication processes, we ensure dependable structural performance and maximum load distribution within concrete foundations. Whether for standard construction requirements or bespoke assemblies tailored to unique engineering drawings, we provide a complete, high-quality manufacturing solution.
| TO SUIT | A | B | C | E | F | G |
|---|---|---|---|---|---|---|
| Bolt Size | mm | mm | mm SQ | mm | mm | mm |
| M20 x 50 | 198 | 180 | 60 | 50 | 8 | 22 - 28 |
| M24 x 60 | 240 | 220 | 70 | 60 | 8 | 27 - 34 |
| M30 x 80 | 300 | 278 | 80 | 75 | 10 | 33 - 42 |
| M36 x 80 | 308 | 283 | 90 | 90 | 10 | 40 - 51 |
| M42 x 80 | 397 | 370 | 100 | 105 | 12 | 57 - 59 |
| M48 x 120 | 408 | 377 | 120 | 120 | 16 | 53 - 68 |
| M56 x 140 | 420 | 389 | 130 | 140 | 16 | 62 - 79 |
