Leading UK Manufacturer of Sling Rod Eyebolts (Integral Forged Eye).
We specialise in the precision manufacture and supply of high-integrity sling rod eyebolts featuring an integral forged eye, produced in accordance with BS 3974.
Engineered for reliable lifting, suspension, and support applications, these components offer exceptional structural continuity and load-bearing performance.
Utilising advanced in-house hot-forging and precision-machining processes, we ensure consistent dimensional accuracy and structural integrity. Whether for standard piping support requirements or bespoke designs tailored to unique engineering drawings, we provide a complete, high-quality manufacturing solution.
| A | B | C | D | E | SWL | Weight Each |
|---|---|---|---|---|---|---|
| mm | mm | mm | mm | mm | kgs | kgs |
| M8 | 300 | 200 | 14 | 6 | 230 | 0.13 |
| M10 | 300 | 200 | 16 | 7 | 360 | 0.21 |
| M12 | 300 | 200 | 18 | 9 | 530 | 0.32 |
| M16 | 300 | 200 | 22 | 12 | 1010 | 0.55 |
| M20 | 300 | 200 | 26 | 14 | 1580 | 0.89 |
| M24 | 300 | 200 | 30 | 17 | 2280 | 1.25 |
| M30 | 300 | 200 | 36 | 21 | 3650 | 1.93 |
| M36 | 300 | 200 | 42 | 26 | 5340 | 2.90 |
| M42 | 300 | 200 | 48 | 30 | 7400 | 4.05 |
