Leading UK Manufacturer of Eyebolts with Reduced Eye Thickness.
We specialise in the precision manufacture and supply of high-integrity eyebolts featuring reduced eye thickness.
Engineered for specialised mechanical linkages, compact assemblies, and applications where clearance constraints prevent the use of standard-profile eyebolts, these components provide reliable pivoting and anchoring without sacrificing performance.
Utilising advanced in-house hot-forging and precision-machining processes, we ensure consistent dimensional accuracy and structural integrity. Whether for custom machine design or retrofitting existing systems, we provide a complete, high-quality manufacturing solution.
| A | B | C | D | E | F | ||||
|---|---|---|---|---|---|---|---|---|---|
| mm | inches | mm | MIN mm | MAX mm | MIN mm | MAX mm | MIN mm | MAX mm | mm |
| M8 | 5/16 | 19 | 5 | 7 | 30 | 800 | 15 | 200 | Hole drilled to suit customer requirements. |
| M10 | 3/8 | 22 | 6 | 9 | 34 | 900 | 15 | 200 | |
| 3/8 | 25 | 6 | 9 | 34 | 900 | 15 | 300 | ||
| M12 | 1/2 | 25 | 6 | 11 | 40 | 1000 | 15 | 300 | |
| 1/2 | 32 | 6 | 11 | 40 | 1000 | 15 | 450 | ||
| M16 | 5/8 | 32 | 7 | 15 | 45 | 1300 | 20 | 450 | |
| 5/8 | 38 | 7 | 15 | 45 | 1300 | 20 | 500 | ||
| M20 | 3/4 | 38 | 7 | 19 | 55 | 1500 | 25 | 500 | |
| 3/4 | 42 | 7 | 19 | 55 | 1500 | 25 | 500 | ||
| 3/4 | 50 | 7 | 19 | 60 | 1500 | 25 | 500 | ||
| M22 | 7/8 | 50 | 10 | 21 | 70 | 1500 | 30 | 500 | |
| M24 | 1 | 50 | 12 | 22 | 75 | 1500 | 30 | 650 | |
| - | 62 | 12 | 22 | 80 | 1500 | 35 | 650 | ||
| M27 | - | 60 | 13 | 25 | 80 | 1500 | 35 | 800 | |
| M30 | 1. 1/8 | 60 | 13 | 28 | 80 | 1500 | 38 | 1000 | |
| M33 | 1. 1/4 | 65 | 14 | 32 | 85 | 1500 | 40 | 1000 | |
| M36 | 1. 3/8 | 65 | 16 | 35 | 95 | 2000 | 40 | 1500 | |
| M39 | 1. 1/2 | 89 | 18 | 38 | 100 | 2000 | 45 | 1500 | |
| M42 | 1. 5/8 | 90 | 20 | 40 | 110 | 2000 | 50 | 1500 | |
