Leading UK Manufacturer of DIN 529 Type F Anchor Bolts
We specialise in the precision manufacture and supply of high-integrity DIN 529 Type F anchor bolts.
Engineered with a distinct wedge shape head geometry, this design provides a robust mechanical anchor point, locking securely into concrete foundations to resist high pull-out forces.
Utilising advanced in-house hot-forging, precision pressing, and machining processes, we ensure consistent dimensional accuracy and structural performance in accordance with the DIN 529 standard. Whether for standard construction requirements or bespoke modifications, we provide a complete, high-quality manufacturing solution.
| D | A | C | S | B | L |
|---|---|---|---|---|---|
| mm | mm | mm | mm | mm | mm |
| M8 | 14 | 50 | 6 | To Customer Requirements | |
| M10 | 16 | 50 | 8 | ||
| M12 | 20 | 55 | 10 | ||
| M16 | 25 | 85 | 14 | ||
| M20 | 30 | 95 | 18 | ||
| M24 | 35 | 120 | 22 | ||
| M30 | 45 | 130 | 26 | ||
| M36 | 55 | 190 | 30 | ||
| M42 | 65 | 200 | 36 | ||
| M48 | 75 | 220 | 42 | ||
