Leading UK Manufacturer of DIN 529 Type E Anchor Bolts.
We specialise in the precision manufacture and supply of high-integrity DIN 529 Type E anchor bolts.
This variant is engineered as an indented foundation bolt, featuring a distinctive indented shank pattern specifically designed to maximize mechanical bonding and grip strength within concrete foundations.
Utilising advanced in-house hot-forging, pressing, and machining processes, we ensure consistent dimensional accuracy and structural performance in accordance with the DIN 529 standard. Whether for standard construction requirements or bespoke variations, we provide a complete, high-quality manufacturing solution.
| D | A | C | B | L |
|---|---|---|---|---|
| mm | mm | mm | mm | mm |
| M8 | 16 | 45 | To Customer Requirements | |
| M10 | 20 | 55 | ||
| M12 | 24 | 70 | ||
| M16 | 32 | 90 | ||
| M20 | 40 | 100 | ||
| M24 | 48 | 135 | ||
| M30 | 60 | 150 | ||
| M36 | 72 | 180 | ||
| M42 | 85 | 260 | ||
| M48 | 98 | 260 | ||
