Leading UK Manufacturer of DIN 529 Type D Anchor Bolts.
We specialise in the precision manufacture and supply of high-integrity DIN 529 Type D anchor bolts.
This variant is engineered with a wavy pressed tail end, providing superior load distribution and enhanced pull-out resistance when cast into concrete foundations.
Utilising advanced in-house hot-forging, press forming, and machining processes, we ensure consistent dimensional accuracy and structural performance in accordance with the DIN 529 standard. Whether for standard construction requirements or bespoke variations, we provide a complete, high-quality manufacturing solution.
| D | A | C | S | B | L |
|---|---|---|---|---|---|
| mm | mm | mm | mm | mm | mm |
| M8 | 16 | 24 | 3 | To Customer Requirements | |
| M10 | 20 | 30 | 3.5 | ||
| M12 | 24 | 36 | 4 | ||
| M16 | 32 | 48 | 5 | ||
| M20 | 40 | 60 | 6 | ||
| M24 | 48 | 72 | 8 | ||
