Leading UK Manufacturer of DIN 529 Type C Anchor Bolts.
We specialise in the precision manufacture and supply of high-integrity DIN 529 Type C anchor bolts.
This variant is engineered with a split 'fish tail' geometry, providing a secure mechanical anchor point designed to embed effectively into concrete and masonry foundations.
Utilising advanced in-house hot-forging, precision bending, and machining processes, we ensure consistent dimensional accuracy and structural performance in accordance with the DIN 529 standard. Whether for standard construction requirements or bespoke variations, we provide a complete, high-quality manufacturing solution.
| D | A | C | B | L |
|---|---|---|---|---|
| mm | mm | mm | mm | mm |
| M8 | 16 | 12 | To customer requirements. | |
| M10 | 20 | 15 | ||
| M12 | 24 | 18 | ||
| M16 | 32 | 24 | ||
| M20 | 40 | 30 | ||
| M24 | 48 | 36 | ||
| M30 | 60 | 45 | ||
| M36 | 72 | 54 | ||
| M42 | 85 | 63 | ||
| M48 | 98 | 72 | ||
| M56 | NON STANDARD SIZES ON REQUEST | |||
| M64 | ||||
| M72 | ||||
