Leading UK Manufacturer of DIN 529 Type B Anchor Bolts.
We specialise in the precision manufacture and supply of high-integrity DIN 529 Type B anchor bolts.
Engineered with a cranked shank geometry, this design provides a robust mechanical anchor point, locking securely into concrete and masonry foundations to resist pull-out forces under heavy loads.
Utilising advanced in-house hot-forging, precision bending, and machining processes, we ensure consistent dimensional accuracy and structural performance in accordance with the DIN 529 standard. Whether for standard construction requirements or bespoke modifications, we provide a complete, high-quality manufacturing solution.
| D | A | C | B | L |
|---|---|---|---|---|
| mm | mm | mm | mm | mm |
| M8 | 24 | 20 | To Customer Requirements | |
| M10 | 30 | 25 | ||
| M12 | 36 | 30 | ||
| M16 | 48 | 40 | ||
| M20 | 60 | 50 | ||
| M24 | 75 | 60 | ||
| M30 | 95 | 75 | ||
| M36 | 115 | 90 | ||
| M42 | 135 | 105 | ||
| M48 | 155 | 120 | ||
| M56 | 180 | 140 | ||
| M64 | 200 | 160 | ||
| M72 | 240 | 180 | ||
