Leading UK Manufacturer of Basic Spade Connector Ends.
We specialise in the precision manufacture and supply of high-integrity Basic Spade Connector Ends, engineered as an essential flat-pin connection component for architectural tension systems, tie rod assemblies, and structural bracing.
Designed with a flattened, pierced spade profile on one end and a threaded shank on the other, our spade connectors facilitate smooth pin-and-plate connections within structural frameworks.
Utilising advanced in-house hot forging, profile cutting, machining, and threading facilities, we ensure consistent structural performance, optimal material grain flow, and precise pin-hole tolerances across every production run.
| D | A1 | A2 | A3 | D1 | G | L1 | L2 | L3 |
|---|---|---|---|---|---|---|---|---|
| Thread | mm | mm | mm | mm | mm | mm | mm | mm |
| M8 | 16 | 16 | 8 | 8 | 12 | 42 | 32 | 20 |
| M10 | 20 | 20 | 10 | 10 | 15 | 52 | 40 | 25 |
| M12 | 24 | 24 | 12 | 12 | 18 | 62 | 48 | 30 |
| M16 | 32 | 32 | 16 | 16 | 24 | 83 | 64 | 40 |
| M20 | 40 | 40 | 20 | 20 | 30 | 105 | 80 | 50 |
Larger sizes on request.
Available in Right Hand (RH) Or Left Hand (LH) Thread.
