Leading UK Manufacturer of Lewis Lifting Pins.
We specialise in the precision manufacture and supply of high-integrity Lewis lifting pins, designed specifically as reliable lifting aids for positioning stonework during straight vertical lifts.
Available in five standard sizes across safe working load (SWL) ranges from 250kg up to 2000kg, our tested and certified pins deliver dependable performance for masonry and architectural handling.
Utilising advanced in-house forging, bending, and machining processes, we ensure consistent dimensional accuracy and structural reliability across every production run. Whether for standard lifting requirements or bespoke pin dimensions tailored to unique stone weights and hole configurations, we provide a complete, high-quality manufacturing solution.
| Part Number | SWL | A | B | C | D | E | F | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ton | kgs | inch | mm | inch | mm | inch | mm | inch | mm | inch | mm | inch | mm | |
| BFD6000 | 0.25 | 250 | 3.000 | 76 | 2.000 | 51 | 0.790 | 20 | 0.470 | 12 | 5.000 | 127 | 0.750 | 19 |
| BFD6001 | 0.50 | 500 | 3.000 | 76 | 2.000 | 51 | 0.790 | 20 | 0.470 | 12 | 5.000 | 127 | 1.000 | 25.4 |
| BFD6015 | 1.00 | 1000 | 3.000 | 76 | 3.000 | 76 | 0.980 | 25 | 0.630 | 16 | 5.000 | 127 | 1.125 | 28.6 |
| BFD6016 | 1.50 | 1500 | 3.000 | 76 | 3.000 | 76 | 0.980 | 25 | 0.790 | 20 | 5.000 | 127 | 1.250 | 31.8 |
| BFD6002 | 2.00 | 2000 | 4.250 | 108 | 3.000 | 76 | 1.260 | 32 | 0.790 | 20 | 5.000 | 127 | 1.375 | 35 |
NOTES:
Lewis Pins are lifting aids only, suitable for positioning stonework during straight vertical lifts.
Ropes or slings must always be used for lifting and moving any stonework.
The lewis pin can slip out if the stonework’s weight changes suddenly, from bumps, etc.
The drilled hole (to suit F) must be prepared to fit the lewis pin tightly, or premature failure may occur.
