Leading UK Manufacturer of Basic Clevis Ends with External Threads.
We specialise in the precision manufacture and supply of high-integrity Basic Clevis Ends complete with External (Male) Threads, engineered as a reliable pivot connection for tension systems, pneumatic cylinders, and mechanical linkages.
Unlike standard internally threaded clevis options, these components feature a protruding male stud shank, allowing direct connection into tapped components, female couplers, or actuation rods.
Utilising advanced in-house hot forging, thread rolling, and precision machining cells, we ensure consistent mechanical performance, accurate thread alignment, and robust load-bearing capacities across every production run.
| D | A1 | A2 | D1 | L1 | L2 | L3 | L4 | L5 |
|---|---|---|---|---|---|---|---|---|
| Thread | mm | mm | mm | mm | mm | mm | mm | mm |
| M8 | 8 | 16 | 8 | 57 | 47 | 25 | 20 | 16 |
| M10 | 10 | 20 | 10 | 69 | 57 | 30 | 25 | 20 |
| M12 | 12 | 24 | 12 | 82 | 68 | 35 | 30 | 24 |
| M14 | 14 | 27 | 14 | 94 | 78 | 40 | 35 | 28 |
| M16 | 16 | 32 | 16 | 108 | 89 | 45 | 40 | 32 |
| M20 | 20 | 40 | 20 | 134 | 109 | 55 | 50 | 40 |
Larger sizes can be manufactured upon request.
Available in Right Hand (RH) or Left Hand (LH) thread.
Similar to DIN 71752 / DIN ISO 8140.
