Leading UK Manufacturer of BS 3032 Small D-Shackles (Dee Shackles)
We specialise in the precision manufacture and supply of high-integrity small D-shackles, engineered strictly in accordance with BS 3032 Table 1 specifications for demanding lifting, rigging, and marine applications.
Designed with a streamlined, compact internal profile for applications where clearance is restricted or tighter connection geometry is required, our heavy-duty dee shackles deliver dependable inline load management under intense operating conditions.
Utilising advanced in-house hot-forging, heavy bending, and machining capabilities, we ensure consistent structural performance, optimal material grain flow, and superior tensile strength across every production run. Whether supplying standard BS 3032 configurations or fully bespoke hot-forged specials tailored to unique project requirements, we provide a complete, high-quality manufacturing solution.
| SWL | d | D | W | R | S | E | Weight Each | |
|---|---|---|---|---|---|---|---|---|
| Tons | cwt | inches | inches | inches | inches | inches | inches | kgs |
| --- | 6 | 1/4 | 3/8 | 3/8 | 7/8 | 3/4 | 0.1 | 0.1 |
| --- | 12 | 3/8 | 1/2 | 5/8 | 1.3/8 | 1 | 0.1 | 0.1 |
| 1 | 0 | 1/2 | 5/8 | 7/8 | 1.7/8 | 1.1/4 | 0.3 | 0.3 |
| 1 | 15 | 5/8 | 3/4 | 1 | 2.1/4 | 1.1/2 | 0.6 | 0.6 |
| 2 | 10 | 3/4 | 7/8 | 1.1/4 | 2.3/4 | 1.3/4 | 1.0 | 1.0 |
| 3 | 10 | 7/8 | 1 | 1.3/8 | 3.1/4 | 2 | 1.5 | 1.5 |
| 4 | 10 | 1 | 1.1/8 | 1.1/2 | 3.5/8 | 2.1/4 | 2.3 | 2.3 |
| 5 | 10 | 1.1/8 | 1.1/4 | 1.3/4 | 4.1/8 | 2.1/2 | 3.3 | 3.3 |
| 7 | 0 | 1.1/4 | 1.3/8 | 1.7/8 | 4.1/2 | 2.3/4 | 4.5 | 4.5 |
| 8 | 0 | 1.3/8 | 1.1/2 | 2.1/8 | 5 | 3 | 6.0 | 6.0 |
| 10 | 15 | 1.1/2 | 1.3/4 | 2.3/8 | 5.1/2 | 3.1/2 | 8.6 | 8.6 |
| 13 | 0 | 1.5/8 | 1.7/8 | 2.1/2 | 5.7/8 | 3.3/4 | 9.5 | 9.5 |
| 14 | 15 | 1.3/4 | 2 | 2.3/4 | 6.3/8 | 4 | 12.5 | 12.5 |
| 16 | 15 | 1.7/8 | 2.1/8 | 2.7/8 | 6.3/4 | 4.1/4 | 15.3 | 15.3 |
| 19 | 0 | 2 | 2.1/4 | 3 | 7.1/4 | 4.1/2 | 18.4 | 18.4 |
| 20 | 0 | 2.1/8 | 2.3/8 | 3.1/4 | 7.3/4 | 4.3/4 | 22.3 | 22.3 |
| 25 | 0 | 2.3/8 | 2.3/4 | 3.5/8 | 8.5/8 | 5.1/2 | 30.9 | 30.9 |
| 30 | 0 | 2.1/2 | 2.7/8 | 3.7/8 | 9 | 5.3/4 | 35.9 | 35.9 |
| 35 | 0 | 2.3/4 | 3.1/8 | 4.1/4 | 10 | 6.1/4 | 48.1 | 48.1 |
| 40 | 0 | 2.7/8 | 3.1/4 | 4.3/8 | 10.3/8 | 6.1/2 | 54.9 | 54.9 |
| 50 | 0 | 3.1/4 | 3.3/4 | 5 | 10.3/4 | 7.1/2 | 79.0 | 79.0 |
| 65 | 0 | 3.5/8 | 4.1/4 | 5.1/2 | 13.1/8 | 8.1/2 | 109.9 | 109.9 |
| 80 | 0 | 4 | 4.5/8 | 6.1/8 | 14.1/2 | 9.1/4 | 147.6 | 147.6 |
